SPECIFICATIONS
MicroPiezo inkjet, 3 colors with
pigment ink,
Automatic Nozzle Checking
Technology, composite black
Print Resolution
360dpi x 180dpi, 360dpi x 360dpi,
720dpi x 360dpi
Interface
USB 2.0, Ethernet
Printer Driver
For Windows 2000, XP, VISTA and
Windows 2003 Server
Print Font
Requires 1D/2D code generating
utility: UPC-A, UPC-E, JAN13(EAN),
JAN8(EAN), Code39, ITF, Codabar,
Code93, Code128, UCC/EAN-128, UCC/EAN-128M,
RSS14, RSS14-Truncated, RSS-Limited,
RSSExpanded, RSSExpandedM, PDF417,
QR Code, Maxi Code, RSS14 Stacked,
RSS Stacked Omnidirectional, RSS
Expanded Stacked, Composite
Symbology, DataMatrix, Aztec*
Print Speed (Max)
360 dpi x 180 dpi, High-speed mode
69mm/sec. (104mm print width)
{2.7"/sec. (4.1" print width)}
83mm/sec. (72mm print width)
{3.3"/sec. (2.8" print width)}
94mm/sec. (56mm print width)
{3.7"/sec. (2.2" print width)}
360 dpi x 360 dpi, Fine mode
35mm/sec. (104mm print width)
{1.4"/sec. (4.1" print width)}
42mm/sec. (72mm print width)
{1.7"/sec. (2.8" print width)}
47mm/sec. (56mm print width)
{1.9"/sec. (2.2" print width)}
Media Handling Capabilities
Roll-fed or fanfold, die cut or
continuous (plain paper/ adhesive
labels on liner)
Roll-Fed Width
30 to 112.0mm (1.2 to 4.4")
O.D.
102mm (4.0") max.
Die-Cut Label Gap
Min. 3.0mm (0.12")
Black Mark Size (WxH)
Min. 5.0 x 4.0mm (0.20 x 0.16") (Linerless
is not supported)
Media Thickness
Plain Paper
0.08 to 0.15mm (3.15 to 5.91mils)
Label and Liner
0.12 to 0.19mm (4.72 to 7.5mils)
Media Guide
Continuous (stepless) adjustment
with no tool from 30mm to 112mm
(1.2" to 4.4")
Ink Cartridge
Single cartridge with 3 colors (CMY)
Media Sensors
"Gap" and "Black mark sensor"
"Paper end" sensor (no "near end"
sensor)
Media Output Tray
Standard
Auto Cutter
Standard (full cut only)
Reliability
Up to 1.5 million cuts (plain paper
and liner); up to 0.75 million cuts
with no maintenance/up to 1.0
million cuts with blade cleaning
(continuous label)
Power Supply
PS-180
Overall Dimensions
10.0" W x 10.6" D x 10.0" H (255mm W
x 270mm D x 255mm H |
